essential
Article number: BGW34

PURE BASE 500

WINDOW BLACK

Outstanding price-performance ratio

be quiet! Pure Base 500 Window Black combines customizable and silence features with a compact and sophisticated design.

  • Exchangeable top cover for silent or high-performance systems
  • Two preinstalled Pure Wings 2 140mm fans
  • Insulation mats on the front, sides and the regular top cover
  • Water cooling ready for radiators of up to 360mm
  • Generous space for high-end graphics cards and large coolers
  • Various options to install up to five SSDs in total
  • PSU shroud and smart cable routing options provide a neat interior
  • Easy PSU installation from the back of the case
  • Side panel made of tempered glass

REGULAR TOP COVER

Perfect for silent air-cooled systems

The regular top cover perfectly rounds off the design of the Pure Base 500. An insulation mat attached underneath ensures a silent operation. It is the perfect choice for air-cooled systems and regular, silent PC configurations. Strong magnets make sure the top covers fits firmly.

HIGH-PERFORMANCE TOP COVER

Maximum airflow for water-cooled configurations

For all who strive for maximum performance and especially with water-cooled systems, the extremely air-permeable top cover is the right choice. It is made of light meshed fabrics, ensuring the highest airflow possible.

TWO PREINSTALLED PURE WINGS 2

Whisper-quiet operation

Two preinstalled Pure Wings 2 fans with airflow-optimized fan blades that ensure perfect airflow and cooling. Despite the compact case design the front and rear fans are both 140mm models, resulting in very quiet operation. Up to three 140mm fans can be installed in addition.

NOISE DAMPENING

Achieving great silence and stability

The front, sides and regular top cover are equipped with insulation mats that result in great stability and improved noise dampening capabilities. The dust filters on the front and bottom are easy to remove for cleaning.

SOPHISTICATED DESIGN

Generous space for high-end hardware

The Pure Base 500 provides generous dimensions to install high-end graphics cards and large coolers of up to 190mm in height. Fans or a radiator up to 360mm can be installed easily at the front and the top area also provides space for more fans or a radiator up to 240mm.

EYE-CATCHING FEATURES

And great cable routing possibilities

Pure Base 500 offers various possibilities for installing up to five SSDs in total. Two can be installed for prominent viewing through the window panel. To hide any unwanted cables, the case offers excellent cable routing options.

FUNCTIONAL PSU SHROUD

Offering a neat interior

The PSU shroud perfectly covers the cables and PSU. It also contains a double HDD cage with decoupled mountings that reduce vibrations and help maximize the silence. The cage can also be repositioned to install a radiator of up to 360mm at the front. The power supply unit can be easily installed from behind, mounted on the PSU bracket provided.

TEMPERED GLASS WINDOW

A perfect view inside your PC

The high-quality, fully-windowed side panel offers a perfect view of the components inside your PC case. The window is made of tinted and tempered glass with black painted side bars.

All models at a glance:

Features

General data

Model Pure Base 500 | Window Black
PSU form factor ATX PS/2
Motherboard compatibility ATX, M-ATX, Mini-ITX
Case size excl. stands (L x W x H), (mm) 450 x 231 x 443
Installation of motherboards with backplate
Case size incl. stands (L x W x H), (mm) 450 x 231 x 463
Dimensions side panel window (L x W), (mm) 400 x 431.3
Color option Black
Weight (kg) 7.53
USB 2.0 -
USB 3.0 2
USB 3.1 Gen 2 Type C -
HD Audio I/O Mic + Audio
Expansion slots 7
Fan mounting locations 6
Qi charger / Quick Charging Option -

Infographics

open all / close all

Material

Top cover ABS
Side panel Steel
Side panel window Tempered Glass 4mm
Front panel ABS
Stands ABS

Drive bay capacity

5.25 bays 0
3.5 slots (max.) 2
3.5 slots (scope of delivery) 2
2.5 slots (max.) 5
2.5 slots (scope of delivery) 5

Pre-installed fans

Fan @ front 1x be quiet Pure Wings 2 | 140mm
Fan @ rear 1x be quiet Pure Wings 2 | 140mm
Dimensions (L x W x H), (mm) 140 x 140 x 25
Fan speed @ 100% PWM / 12V (rpm) 900
Noise level @ 100% PWM / 12V (dB(A)) 17.1
Airflow @ 100% PWM / 12V (CFM / m3/h) 55.8 / 94.8
Air Pressure @ 100% PWM / 12V (mm H2O) 0.6
Voltage range (V DC) 12
Input power (W) 1.08
Input current (A) 0.09
Connector 3-Pin
Lifespan (h / 25°C) 80,000
Fan controller -

Optional fan installation

Front (mm) 1 x 140 | 3 x 120
Top (mm) 2 x 140 | 2 x 120
Bottom (mm) -
Side panel (mm) -
PSU shroud -

Optional radiator installation

Front (mm) 120, 140, 240, 280, 360
Top (mm) 120, 240
Bottom (mm) -
Rear (mm) 120 / 140

Cooling

Max.construction height of CPU cooler unit (mm) -
Airflow channel -

Lighting

RGB LED illumination -
LEDs synchronizable with RGB controller/motherboard -
Expandable RGB controller -

PSU compatibility

Maximum dimensions excl. bottom fan (mm) 258
Maximum dimensions incl. bottom fan (mm) 225

Graphics card

HDD cage (in height of graphics card) installed (mm) 369
HDD cage (in height of graphics card) removed (mm) 369

Insulation and damping

Top panel insulation mats
Front panel insulation mats
Side panel insulation mats
Anti-vibration decoupled HDD
Anti-vibration decoupled fan -
Anti-vibration decoupled PSU
Anti-vibration decoupled motherboard-tray -

Removeable dust filters

Front 1
Bottom 1
Side panel 1

Accessories

Screw set (Drives/Motherboard)
Rubber rail (pcs.) -
Standoff (pcs.) -
LCS bracket (pcs). -
HDD slot cover (pcs.) -
Upper fan bracket (pcs.) -
HDD panel rubber grommet (pcs.) -
SSD bracket for PSU shroud -
LED strips (pcs.) -
Cable ties (pcs.) 6 | 4 (Velcro)
Cable tie holder (pcs.) -

Service

Warranty (Years) 3
International hotline / free of charge ✓ / DE, FR

Logistics data, RRP

Article number BGW34
EAN code 4260052187791
Certifications CE, RoHS
Dimensions, package (L x W x H), (mm) 510 x 285 x 494
Gross weight, package (kg) 8.49
Pieces per packaging unit 1
RRP (€) 79.90
