Article number: BGW20

PURE BASE 600

Window Orange

Exceptionally silent and functional

Pure Base 600 Window offers a great deal of functionality and features for an attractive price.

  • Highly versatile, with repositionable HDD slots and removable ODD cage
  • Water cooling ready for radiators up to 360mm on front, top and rear
  • Adjustable top cover vent with enhanced cooling options and mounting location for a radiator
  • 2 pre-installed be quiet! Pure Wings 2 fans assure whisper-quiet operation
  • Fully windowed side panel from tempered glass
  • Completely sound insulated with dampening material in all relevant places
  • 3-year manufacturer’s warranty
  • German product conception, design and quality control
No YouTube
Functionality cookies are not set.
You cannot proceed without functionality cookies. Please activate them. More information.

HIGHLY VERSATILE CONSTRUCTION

Maximum of possibilities for your desired system

Pure Base 600 offers many possibilities for system component selection. The 3 HDD slots can be repositioned to allow installation of the largest of graphics cards and the ODD cage is removable for maximum flexibility of water cooling and drives.

OPTIMIZED FOR RADIATORS

Full choice for water cooling

Pure Base 600 was optimized to be the perfect case for liquid cooling. 3 areas are specially designed to allow them to be added: front, top and rear. All sizes of radiator up to 360mm are possible.

ADJUSTABLE TOP COVER VENT

Ingenious concept for water cooling and silence

The Pure Base 600 top cover is adjustable allowing choice between boosting your system’s cooling or silence. You can close it for more silence, open it partially for more exhaust or leave it open to mount a water cooling radiator.

PRE-INSTALLED PURE WINGS 2 FANS

Whisper-quiet operation – typical for be quiet!

2 pre-installed Pure Wings 2 fans with 9 airflow-optimized fan blades reduce turbulence and increase air pressure: 120mm at the rear, 140mm at the front. Permits up to four additional cooling fans.

KEEP THE SYSTEM SUPER SILENT

Equipped with smart and effective silence features

Integrated 3-step fan controller supports 3 fans. Sound insulating material on top, side and front that dampens vibration. Filters at front and bottom prevent the dust to come into the case.

TEMPERED GLASS WINDOW

See your valuable components

The high-quality and fully-windowed side panel offers a perfect view of components inside your chassis. The window is made of 4mm tinted and tempered glass, and is decoupled from the case with rubber elements to inhibit the transfer of vibrations.

“How to combine the well-known be quiet! silence with a user-friendly design? This was the challenge we were facing during development of Pure Base 600. The outcome is one of our most popular cases to this day with countless sales all over the world. So we are certain that we have successfully fulfilled this mission.”

Bryan Lu, Leader of PC Cases

All models at a glance:

Product Series

General data

ModelPure Base 600 Window Orange
Color optionOrange
Motherboard compatibilityATX / M-ATX / Mini-ITX
Case size excl. stands (L x W x H), (mm)492 x 220 x 445
Case size incl. stands (L x W x H), (mm)492 x 220 x 470
Volume (l)48.17
PSU form factorATX PS/2
Net weight (kg)8.5
Expansion slots7

Infographics

open all / close all

Pre-installed fans

Fan at top-
Fan at front1x Pure Wings 2 140mm
Fan at side-
Fan at rear1x Pure Wings 2 120mm
Fan at bottom-
Dimensions (L x W x H), (mm)Front: 140 x 25 x 140 / Rear: 120 x 25 x 120
Fan speed at 100% PWM / 12V (rpm)Front: 900 / Rear: 1200
Airflow at 100% PWM / 12V (CFM / m3/h)Front: 55.8/94.8 / Rear: 41.7/70.84
Air Pressure at 100% PWM / 12V (mm H2O)Front: 0.6 / Rear: 0.9
Noise level at 100% PWM / 12V (dB(A))Front: 17.1 / Rear: 16.8
Voltage range (V DC)5 - 12
Input power (W)Front: 1.1 / Rear: 1.0
Input current (A)0.09
Connector3-pin
Lifespan (h / 25°C)80,000
Fan controllerManual 3-step fan controller (3x 3-pin)

Maximum fan installation

Maximum fans6
Top (mm)3x 120 / 2x 140
Front (mm)2x 120 / 2x 140
Side (mm)-
Rear (mm)1x 120
Bottom (mm)-
PSU shroud-

Optional radiator installation

Top (mm)120 / 240 / 360
Front (mm)120 / 140 / 240 / 280 / 360
Side (mm)-
Rear (mm)120
Bottom (mm)-

PSU compatibility

Maximum dimensions excl. bottom fan (mm)210
Maximum dimensions incl. bottom fan (mm)210

Graphics card

HDD cage (in height of graphics card) installed (mm)280
HDD cage (in height of graphics card) removed (mm)425
Maximum PCIe slots with vertical graphics card (pcs.)-

Drive bay capacity

5.25 bays (pcs.)2
3.5 slots (scope of delivery)3
3.5 slots (max.)5
2.5 slots (scope of delivery)8
2.5 slots (max.)12

Cooling

Max.construction height of CPU cooler unit (mm)165
Airflow channelFront / Top

Lighting

LED illumination-
LEDs (pcs.)-
LED type-
LEDs synchronizable with controller/motherboard-

I/O Panel

USB 3.2 Gen. 2 Type C-
USB 3.2 Type A2
USB 2.0-
HD Audio I/OMic + Audio
Qi charger / Quick Charging Option (W)-

Insulation and damping

Top panel insulation mats
Front panel insulation mats
Side panel insulation mats
Anti-vibration decoupled HDD
Anti-vibration decoupled fan-
Anti-vibration decoupled PSU
Anti-vibration decoupled motherboard-tray-

Scope of delivery

Screw set (Drives/Motherboard)
Additional standoffs (pcs.)-
SSD bracket for PSU shroud-
LED strips (pcs.)-
Cable ties (pcs.)4
Screw box-
VGA holder-
VGA holder for inverted layout-
Mesh Front Panel-
ODD Bracket-
Fan / Radiator bracket for multi mounting panel-

Removeable dust filters

Top-
Front1
Side-
Bottom1

Material

Top coverABS
Front panelABS
Side panelSteel
Side panel windowTempered glass
StandsABS

Safety certification

ApprovalsCE, UKCA

Environmental directives

RoHS
Reach
WEEE-
Triman

Service

Warranty (Years)3
International hotline / free of charge✓ / DE, FR, US

Logistics data and RRP

Article numberBGW20
EAN code4260052185438
Dimensions, package (L x W x H), (mm)515 x 280 x 565
Gross weight, package (kg)9.84
Pieces per packaging unit1
RRP (€)114.90
