The be quiet! Dark Power 12 750W offers 80 PLUS® Titanium efficiency and a virtually inaudible frameless fan concept for flawless cooling.
6 PCI express connectors for overclocked high-end GPUs
Dark Power 12 750W is certified with 80 PLUS Titanium and an energy efficiency rating of up to 95.9%. This provides lots of benefits for your high-end system, including less power consumption and an overall cooler and quieter operation. The standby drain is below 0.1 watts.
The be quiet! Silent Wings fan mounted on a tripod enables maximum airflow and a virtually inaudible operation. This is thanks to its unique, airflow-optimized fan blade design along with an advanced fluid-dynamic bearing and 6-pole fan motor for less vibration, super-long life and minimal power consumption.
The split fan inlet of the Dark Power 12 750W is a custom-shaped funnel that increases airflow while reducing unwanted turbulence. The wire-free design inside allows the cool air to reach all components flawlessly which ultimately leads to a longer lifespan.
Dark Power 12 750W is particularly suitable for overclocking, thanks to its strong and stable 12V rails. The overclocking key gives you full overclocking control by manually switching between the default four 12V rail mode and the alternative massive single-rail operation.
The maximum utility provided by modular sleeved cables of up to 120cm simplifies component installation and reduces annoying clutter. This results in increased airflow and improved cooling in even the largest PC cases.
With an active rectifier and full bridge LLC technology Dark Power 12 750W offers some of the most advanced technologies available, resulting in higher efficiency, better regulation and lower ripple noise for an incomparably stable operation.
Only the best components are used in Dark Power 12 750W. That is why we have exclusively built high-quality Japanese capacitors into the PSU chassis. They are rated to 105°C which ensures stability, reliability and a long operating life.
|Model||Dark Power 12 750W|
|Continuous power (W)||750|
|Peak power (W)||850|
|Form factor||Version 2.52|
|Form factor EPS 12V||Version 2.92|
|Topology||Active Rectifier + Full bridge + LLC + SR + DC/DC|
|Voltage (Vac)||100 - 240|
|Frequency (Hz)||50 - 60|
|Input current (A)||9 / 4.5|
|Power factor at 100% load||>0.97|
|Power consumption in standby (W)||<0.06|
|Average life time (h / 25°C)||200,000|
|Operating temperature up to (°C)||40|
|80 PLUS certification||Titanium|
|Efficiency (%) at 230V, 2% load||-|
|Efficiency (%) at 230V, 10% load||-|
|Efficiency (%) at 230V, 20% load||94.8|
|Efficiency (%) at 230V, 50% load||95.9|
|Efficiency (%) at 230V, 100% load||93.8|
|Fan size (mm)||135|
|Motor technology||6-pole fan motor|
|Max. fan speed (rpm)||1800|
|dB(A) at 10% load||-|
|dB(A) at 20% load||8.3|
|dB(A) at 50% load||8.4|
|dB(A) at 100% load||19.6|
|Multi-rail operation (12V rails)||4|
|12V single rail operation||✓|
|Max. combined power 12V (W)||744|
|Max. combined power 3.3V + 5V (W)||110|
|Hold-up time at 100% load (ms)||20.2|
|Power good signal (ms)||100 - 150|
|Maximum cable length (cm)||120|
|Cable length to motherboard (cm)||60|
|No. of cables||13|
|12VHPWR cable / W||-|
|PCI-e 6+2-pin (GPU)||6|
|PCI-e 6-pin (GPU)||-|
|OTP (over temperature protection)||✓|
|OCP (over current protection)||✓|
|OPP (over power protection)||✓|
|SCP (short circuit protection)||✓|
|OVP (over Voltage protection)||✓|
|UVP (under Voltage protection)||✓|
|SIP (Surge & Inrush Protection)||✓|
|Velcro cable ties||✓|
|User manual languages||CN, DE, EN, ES, FR, JP, PL, RU, TW|
|OCK slot bracket with switch / OCK jumper||✓|
|SFX-to-ATX adapter bracket||-|
|Dimensions without cable (L x W x D), (mm)||175 x 150 x 86|
|Express replacement service in first year||DE, FR|
|International hotline / free of charge||✓ / DE, FR|
|Dimensions, package (L x W x H), (mm)||270 x 350 x 120|
|Gross weight, package (kg)||4.18|
|Pieces per packaging unit||4|
|Dimensions, shipping box (L x W x H), (mm)||504 x 305 x 368|
|Gross weight, shipping box (kg)||18.06|
