Article number: BN320
SFX POWER 3
300WCompact and silent energy
SFX Power 3 300W, the first choice compact PSU for mini and media PCs with 80 PLUS® Bronze and PCIe graphics card support. SFX Power 3 300W offers the ideal combination of power, quietness and reliability.
- Strong 12V rail with 300W of continuous power
- 6+2 pin PCIe connector for GPU support
- High-quality temperature-controlled 80mm fan for quiet operation of max. 29.4dB(A)
- Sleeved or flat black cables up to 60cm
- 80 PLUS® Bronze efficiency (up to 89.2%)
- Meets the latest safety and efficiency requirements
- 3-year manufacturer’s warranty
- Product conception, design and quality control in Germany
Functionality cookies are not set.
You cannot proceed without functionality cookies. Please activate them. More information.
You cannot proceed without functionality cookies. Please activate them. More information.
Characteristics
STRONG 12V RAIL
For a stable PCIe graphics supportA PCIe connector provides power for a demanding graphics card. Safety protections defend against overcurrents, over- and undervoltages, short circuits and overloads, thus keeping your valuable components safe.
300 WATTS CONTINUOUS POWER OUTPUT
Ensures a steady and reliable operationThe SFX Power 3 can deliver 300W of continuous power. This ensures a steady and reliable operation even when your PC meets an unexpectedly heavy load.
QUIET AND EFFICIENT OPERATION
For mini or media PCsThe high-quality temperature-controlled 80mm fan allows quiet operations of max. 29.4dB(A). The 80 PLUS Bronze certification with an efficiency rating of up to 89.2% is convincing evidence of this PSU’s power saving operation.
“Users with mini ITX PCs or overall compact systems also deserve a quiet and powerful PSU with up to 80PLUS® Gold efficiency. With this in mind, we have developed the SFX Power series. To all whom it concerns: you are welcome.”
Christian Rex, Head of BU PSU
All models at a glance:
General data
| Model | SFX Power 3 300W |
| Continuous power (W) | 300 |
| Peak power (W) | 350 |
| Form factor | SFX12V Version 3.42 |
| Form factor EPS 12V | Version 2.92 |
| Topology | DC/DC |
| Digitally controlled | - |
| Voltage (Vac) | 100 - 240 |
| Frequency (Hz) | 50 - 60 |
| Input current (A) | 5 / 2 |
| Power factor at 100% load | >0.98 |
| Modern standby | ✓ |
| Power consumption in standby (W) | <0.11 |
| Average life time (h / 25°C) | 100,000 |
| Operating temperature up to (°C) | 40 |
Infographics
Efficiency
| 80 PLUS certification | Bronze |
| Efficiency (%) at 230V, 2% load | - |
| Efficiency (%) at 230V, 10% load | 76.9 |
| Efficiency (%) at 230V, 20% load | 84.4 |
| Efficiency (%) at 230V, 50% load | 89.2 |
| Efficiency (%) at 230V, 100% load | 88.1 |
Fan and cooling technology
| Fan | High quality fan |
| Fan size (mm) | 80 |
| Bearing technology | Rifle |
| Motor technology | 4-pole fan motor |
| Max. fan speed (rpm) | 1979 |
| dB(A) at 10% load | 14.4 |
| dB(A) at 20% load | 14.4 |
| dB(A) at 50% load | 14.4 |
| dB(A) at 100% load | 29.4 |
Output
| Multi-rail operation (12V rails) | - |
| 12V single rail operation | ✓ |
| Overclocking key | - |
| +3.3V (A) | 16 |
| +5V (A) | 16 |
| +12V1 (A) | 25 |
| +12V2 (A) | - |
| +12V3 (A) | - |
| +12V4 (A) | - |
| +12V5 (A) | - |
| +12V6 (A) | - |
| -12V (A) | 0.3 |
| +5Vsb (A) | 2.5 |
| Max. combined power 12V (W) | 300 |
| Max. combined power 12VHPWR (W) | 0 |
| Max. combined power 3.3V + 5V (W) | 85 |
| Hold-up time at 100% load (ms) | 26.8 |
| Hold-up time at 80% load (ms) | - |
| Power good signal (ms) | 100 - 150 |
Cables and connectors
| Modular cables | - |
| Sleeved cables | P24 |
| Flat cables | P4, PCIe, drives |
| Maximum cable length (cm) | 60 |
| Cable length to motherboard (cm) | 35 |
| No. of cables | 5 |
| ATX-Motherboard (20+4-pin) | 1 |
| P4+4 (CPU) | - |
| P8 (CPU) | - |
| P4 (CPU) | 1 |
| 12VHPWR cables | 0 |
| PCI-e 6+2-pin (GPU) | 1 |
| PCI-e 6-pin (GPU) | - |
| SATA | 3 |
| PATA | 2 |
| FDD (Floppy) | 1 |
Protection
| OTP (over temperature protection) | - |
| OCP (over current protection) | ✓ |
| OPP (over power protection) | ✓ |
| SCP (short circuit protection) | ✓ |
| OVP (over Voltage protection) | ✓ |
| UVP (under Voltage protection) | ✓ |
| SIP (Surge & Inrush protection) | ✓ |
Safety certification
| BSMI | - |
| CB | ✓ |
| CCC | - |
| CE | ✓ |
| cRUus | - |
| cTUVus | - |
| CU | ✓ |
| FCC | - |
| RCM | - |
| TÜV | ✓ |
| UKCA | - |
Environmental directives
| Energy Star | 8.0 |
| ErP | ✓ |
| WEEE | ✓ |
| RoHS | ✓ |
| Triman | ✓ |
Scope of delivery
| Thumb screws | - |
| Screws | ✓ |
| Cable ties | ✓ |
| Velcro cable ties | - |
| User manual languages | DE, EN, ES, FR, PL, RU |
| OCK slot bracket with switch / OCK jumper | - |
| SFX-to-ATX adapter bracket | - |
Casing
| Dimensions without cable (L x W x H), (mm) | 100 x 125 x 64 |
| Weight (kg) | 0.84 |
| Color | Black |
Service
| Warranty (Years) | 3 |
| Express replacement service in first year | - |
| International hotline / free of charge | ✓ / DE, FR, US |
Logistics data and RRP
| Article number | BN320 |
| EAN code | 4260052188262 |
| Dimensions, package (L x W x H), (mm) | 75 x 197 x 207 |
| Gross weight, package (kg) | 1.2 |
| Pieces per packaging unit | 6 |
| Dimensions, shipping box (L x W x H), (mm) | 457 x 265 x 233 |
| Gross weight, shipping box (kg) | 7.9 |
| RRP (€) | 57.90 |
