Article number: BW013

Pure Loop 2 FX 240mm is ready for modern flagship CPUs like Intel's Core i9 or AMD's Ryzen 9 series, with room for overclocking.

More information.



Impressive lighting, superior cooling

Pure Loop 2 FX 240mm is the very high-performing and silent All-in-One water cooling unit with impressive ARGB illumination.

  • Very high cooling performance for all mainstream CPUs
  • 2 Light Wings 120mm PWM high-speed fans offer equally high air pressure and vibrant ARGB illumination
  • Doubly decoupled PWM pump for quiet operation and minimal vibration
  • ARGB-PWM-Hub enables synchronization of up to 6 ARGB components and PWM fans
  • Combination of ARGB illumination, all-black design and aluminum-style for unmistakable and stylish look
  • Easy-to-access refill port and included coolant bottle guarantee a long lifespan
  • 3-year manufacturer’s warranty
No YouTube
Functionality cookies are not set.
You cannot proceed without functionality cookies. Please activate them. More information.


Reliable cooling power for sophisticated applications

With Pure Loop 2 FX 240mm even demanding applications can be used reliably. A very high cooling power provides low temperatures even during periods of peak CPU performance. Pure Loop 2 FX 240mm is the water cooling solution of choice for all mainstream CPUs.


Fan blades optimized for high pressure

With a remarkably high air pressure of up to 2.6mm /H2O, Light Wings 120mm PWM high-speed is the best choice for Pure Loop 2 FX 240mm. The 9 airflow-optimized fan blades provide enough air pressure to make this fan perfect, even in demanding configurations.


Lots of illumination possibilities

2 Light Wings PWM high-speed offer ARGB lighting at the front and rear. 18 ARGB LEDs give you many opportunities to individualize your PC build. This and the illuminated cooling block make Pure Loop 2 FX 240mm a highlight in any system.


Adjustable and silent operation

The doubly decoupled PWM-pump runs smoothly and silent. Due to the PWM control the pump speed can be adjusted for silent as well as powerful operations. Thanks to the effective damping the pump causes even less noise and minimal vibration. This is the key to provide the well-known silent be quiet! operation.


Synchronization of up to 6 ARGB-components

The ARGB-PWM-Hub enables synchronization of up to 6 PWM fans and 6 ARGB components. This allows the user to run all your cooling and lighting gear with just one PWM and one ARGB header on your motherboard. It can be positioned everywhere inside the case and by that supports a neat interior and cable management.


For a long lifespan

The refill port is easy to access which makes refilling safe and comfortable. The coolant bottle included in scope of delivery makes it easy to achieve a long lifespan.

“When the be quiet! Light Wings launched, we immediately looked for products to combine them with. Pure Loop 2 FX was one of the very first ideas we got: the progressive AiO and the highly performing Light Wings are the perfect match.”

Aaron Licht, Chief Executive Officer

All models at a glance:

Product Series

General data

ModelPure Loop 2 FX 240mm
Dimensions radiator, incl. fan (H x W x D), (mm)277 x 120 x 52
Dimensions cooling block (H x W x D), (mm)94.5 x 83 x 42
Total weight (kg)1.18
Socket compatibility Intel1700 / 1200 / 2066 / 1150 / 1151 / 1155 / 2011(-3) Square ILM
Socket compatibility AMDAM5 / AM4
Noise level (dB(A)) at 50% / 75% /100% rpm16.7 / 26.3 / 32.3
Number of fans2
Lighting connector3-pin 5V Adressable
Tube length (mm)400
Refill port


open all / close all

Pump specifications

Pump speed (rpm)5500
Pump adjustable (rpm)4000 - 5500
Pump connector4-pin PWM

Radiator specifications

Dimensions (L x W x H), (mm)120 x 277 x 27
Radiator material / finishaluminum / black spray painted
Base material / finishcopper / nickel plated

Fan specifications

Fan model2x Light Wings 120mm PWM high-speed
Fan dimensions (mm)120 x 120 x 25
Speed at 100% PWM (rpm)2500
Airflow at 100% PWM / 12V (CFM / m3/h)52.3 / 88.9
Air Pressure at 100% PWM / 12V (mm H2O)2.6
Bearing technologyRifle
Motor technology4-pole fan motor
Rated Voltage (V)12
Input current (A)0.12
Safety current (A)0.45
Input power (W)5.4
Connector4-pin PWM
Cable length (mm)500
Lifespan (h / 25°C)60,000


Thermal grease (Type)Included
Mounting setIntel, AMD
Adapter cables-
Bottle of coolant (ml)✓ / 100
ARGB controller with SATA cable-
User manual languagesCN, DE, EN, ES, FR, JP, PL, RU, TW

Safety certifications

ApprovalsCE, FCC, UKCA, UL

Environmental directives



Warranty (Years)3
International hotline / free of charge✓ / DE, FR, US

Logistics data and RRP

Article numberBW013
EAN code4260052189023
Dimensions, package (L x W x H), (mm)240 x 321 x 140
Gross weight, package (kg)2.1
Pieces per packaging unit8
Dimensions, shipping box (L x W x H), (mm)658 x 296 x 508
Gross weight, shipping box (kg)18.6
RRP (€)129.90

PURE LOOP 2 FX | 240mm
Article number: BW013
