Article number: BW032
LIGHT LOOP IO LCD
360mmQuiet and Breathtaking
Light Loop IO LCD 360mm Black is an extremely high-performing All-in-One water cooler featuring an IPS display and RGB lighting, designed for heavily overclocked systems.
- Advanced IPS display to show system information, videos, images and a broad spectrum of extensive customization options
- ARGB lighting with vivid presets and individualizations are available via IO Center for Windows
- High cooling performance and whisper-quiet for all consumer CPUs
- 3 daisy-chained Light Wings LX PWM high-speed fans with funnel-shaped air outlets for colorful and vibrant cooling
- State-of-the-art pump with progressive IC
- Flexible sleeved tubes and convenient mounting ensure easy handling and hidden fan cables
Functionality cookies are not set.
You cannot proceed without functionality cookies. Please activate them. More information.
You cannot proceed without functionality cookies. Please activate them. More information.
Characteristics
YOU ARE BREATHTAKING
Outstanding IPS displayThe Light Loop IO LCD 360mm Black has an eye-catching cooling unit with a progressive round IPS display and RGB lighting. With a size of 2.1 inches, a high-resolution display and a display brightness of 500 nits, there are as many customization options as there are unique ways to display information. Whether it's CPU temperatures, coolant temperatures, fan speeds, images, videos, a wide range of presets and much, much more, your CPU cooler will definitely stand out!
WHISPER-QUIET TECHNOLOGIES
One step ahead in every aspectJet plate, pump, and cold plate of the Light Loop IO LCD 360mm Black are engineered for optimal performance at a whisper-quiet noise level. The precision-engineered metal jet plate accelerates cooling liquid flow velocity, delivering superior efficiency. Featuring a high-density fin stack design, the cold plate maximizes heat dissipation for today's flagship and high-performance CPUs. An advanced integrated circuit within the motor minimizes switching noise, ensuring whisper-quiet pump operation.
LIGHT WINGS LX FANS
Performant, yet quiet operationThe setup includes 3 daisy-chained Light Wings LX PWM high-speed fans. Each fan features 16 LEDs that are perfectly distributed across the blades and are key to the stunning visuals the Light Loop IO LCD 360mm Black offers. The fan’s 9 airflow-optimized fan blades not only reduce noise-generating turbulences but also ensure that Light Wings LX PWM high-speed fans provide the performance that is needed, even in demanding scenarios.
EXTREMELY HIGH COOLING PERFORMANCE
Designed for intensive gaming sessionsExperience reliable performance for the most intensive applications. With its powerful cooling capacity, Light Loop IO LCD 360mm Black keeps CPU temperatures down even under maximum load, ensuring you're ready for any demanding task or gaming marathon.
ONE CONTROLLER TO RULE THEM ALL
IO Controller includedOur newly included IO Controller transmits the signal and power to the all-in-one water cooler with just a single cable, allowing for control of the ARGB, PWM and display signals all in one place. In addition, the fan cables are now hidden along the tubes. So, with the Light Loop IO LCD 360mm Black, no additional cables need to be laid from the daisy-chained fans to the mainboard or to a fan hub!
ALL UNDER CONTROL
Customize with the IO CenterThe IO Center for Windows offers many excellent options for customizing the IPS display and lighting of the Light Loop IO LCD 360mm Black. To optimize the water-cooling experience, background effects and the sensor data shown on the display can be adjusted, the lighting of the pump head and fans can be configured, fan profiles can be set up, and the system status can be monitored. In addition, you can save the displayed background and lighting effects directly on the AiO without the need for the software to run continuously.
EASY TO REFILL
For a long lifespanThe refill port is easy to access, which makes refilling safe and convenient. The coolant bottle included in the scope of delivery makes it easy to achieve a long lifespan.
All models at a glance:
General data
| Model | LIGHT LOOP IO LCD | 360mm |
| Color option | Black |
| Dimensions radiator, incl. fan (H x W x D), (mm) | 397 x 120 x 52 |
| Dimensions cooling block (H x W x D), (mm) | 63.8 x 61.9 x 54 |
| Total weight (kg) | 1.6 |
| Socket compatibility Intel | 1851 / 1700 / 1200 / 1151 / 1150 / 1155 |
| Socket compatibility AMD | AM5 / AM4 |
| Noise level (dB(A)) at 50% / 75% /100% rpm | 17.2 / 29.1 / 36.8 |
| Number of fans | 3 |
| Lighting connector | IO connector |
| Tube length (mm) | 400 |
| Refill port | ✓ |
Infographics
Pump specifications
| Pump speed (rpm) | 2900 |
| Pump adjustable (rpm) | 1500 - 2900 |
| Pump connector | IO connector |
Radiator specifications
| Dimensions (L x W x H), (mm) | 397 x 120 x 27 |
| Radiator material / finish | Aluminum |
| Base material / finish | copper / nickel plating |
Fan specifications
| Fan model | Light Wings LX 120mm PWM high-speed |
| Fan dimensions (mm) | 120 x 120 x 25 |
| Speed at 100% PWM (rpm) | 2100 |
| Airflow at 100% PWM / 12V (CFM / m3/h) | 61.8 / 105.1 |
| Air Pressure at 100% PWM / 12V (mm H2O) | 2.51 |
| Bearing technology | Rifle |
| Motor technology | 4-pole |
| Rated Voltage (V) | 12 |
| Input current (A) | 0.17 |
| Safety current (A) | 0.45 |
| Input power (W) | 5.4 |
| Connector | proprietary |
| Cable length (mm) | 20 / 100 + daisy chain |
| Lifespan (h / 25°C) | 60,000 |
Accessories
| Thermal grease (Type) | Included |
| Mounting set | Intel, AMD |
| Adapter cables | ARGB-PWM breakout |
| Bottle of coolant (ml) | 100 |
| ARGB controller with SATA cable | - |
| ARGB-PWM-Hub | - |
| IO Controller | ✓ |
| User manual languages | CN, DE, EN, ES, FR, JP, PL, RU, TW |
Safety certifications
| Approvals | CE, UKCA, FCC |
Environmental directives
| RoHS | ✓ |
| WEEE | ✓ |
| Triman | ✓ |
Service
| Warranty (Years) | 3 |
| International hotline / free of charge | ✓ / DE, FR, US |
Logistics data and RRP
| Article number | BW032 |
| EAN code | 4260052193228 |
| Dimensions, package (L x W x H), (mm) | 448 x 205 x 137 |
| Gross weight, package (kg) | 2.61 |
| Pieces per packaging unit | 4 |
| Dimensions, shipping box (L x W x H), (mm) | 470 x 298 x 445 |
| Gross weight, shipping box (kg) | 11.54 |
| RRP (€) | 229.90 |
