premium
Article number: BN620

STRAIGHT POWER 11

850W Gold

World Class Quiet and Efficiency

be quiet! Straight Power 11 850W raises the bar for systems that demand virtually inaudible operation without power quality compromises.

  • Virtually inaudible Silent Wings 3 135mm fan
  • Funnel-shaped fan opening of the PSU case for high airflow intake
  • Wire-free inside the PSU on the DC side for enhanced cooling and longevity
  • Modular cables for maximum build flexibility
  • 80 PLUS® Gold efficiency (up to 93%)
  • Powerful multi-GPU support with four PCI-Express connectors
  • Japanese 105°C-rated capacitors ensure stability and reliability
  • ErP and Energy Star 6.1 ready
  • 5-year manufacturer’s warranty

SILENT WINGS 3 FAN

Provides virtually inaudible operation

The high-end Silent Wings 3 fan delivers best-of-class airflow yet produces very little noise. This is thanks to its unique, optimized fan blade design along with an advanced fluid-dynamic bearing and 6-pole fan motor that largely eliminates operational noise, has a super-long life and minimal power consumption.

FUNNEL-SHAPED FAN OPENING

Higher cooling performance

The fan inlet of the Straight Power 11 850W is funnel-shaped. It causes an increased throughput of air which benefits to a higher cooling performance.

WIRE-FREE DESIGN INSIDE THE PSU

Pushing the longevity of components to a maximum

An absolute innovation: The Straight Power 11 850W is wire-free on the DC side inside the PSU body. This results in improved cooling airflow and less signal disturbance, simply because of a lack of wiring, and ultimately pushes the lifetimes of the components to a maximum.

MODULAR CABLES

Utmost convenience and compatibility

Thanks to the modular cables, all cables that serve no purpose in the system are left out. For this reason, systems always appear very tidy. At the same time installation is performed much more conveniently. A smoother airflow results from the uncluttered layout of the system, which means lower noise and temperatures prevail inside the case.

80 PLUS® GOLD CERTIFIED

Impressively high efficiency

Straight Power 11 850W is certified with 80 PLUS Gold efficiency, reaching up to 93%. This gives less power consumption and a cooler and quieter operation. Truly a benefit for any system.

HIGH-CLASS TECHNOLOGIES

Compatibility for the systems of tomorrow

The use of LLC and Synchronous Rectifier (SR) provides very stable operation and enhanced voltage regulation. The PSU is equipped with DC-to-DC conversion for tight voltage regulation even under heavy cross-loading conditions. This ensures reliable operation with the next generation of processors and graphics cards.

JAPANESE 105° CAPACITORS

A testament to high quality

Only the best components are used in Straight Power 11 850W. That is why we have built only high-quality Japanese capacitors into the PSU chassis. They are rated to 105°C, ensuring stability, reliability and a long operating life.

All models at a glance:

Features

General data

ModelStraight Power 11 850W
Continuous power (W)850
Peak power (W)920
Form factor ATX 12VVersion 2.4
Form factor EPS 12VVersion 2.92
Modular Cable management
TopologyLLC + SR + DC/DC
Wire-free design (DC-side)
Voltage (Vac)100 - 240
Frequency (Hz)50 - 60
Input current (A)10 / 5
PFCactive
Power factor at 100% load>0.99
Compliant to Intel C6/C7
Power consumption in standby (W)<0.12
Average life time (h / 25°C)100,000
Operating temperature up to (°C)40

Infographics

open all / close all

Output

12V rails (multi-rail operation)4
12V single rail operation-
Overclocking key-
+3.3V (A)25
+5V (A)25
+12V1 (A)21
+12V2 (A)21
+12V3 (A)26
+12V4 (A)26
+12V5 (A)-
+12V6 (A)-
-12V (A)0.5
+5Vsb (A)3
Max. combined power 12V (W)849.6
Max. combined power 3.3V + 5V (W)150
Hold-up time (ms @ 100%)21.1
Power good signal100 - 500ms

Fan / Cooling technology

Fan typeSilent Wings 3
+SilentWings
Motor technology6-pole fan motor
Bearing technologyFDB
Fan size (mm)135
Max. fan speed (rpm), temperature-dependent2100
Temperature control for case fans-
dB(A) at 20% load9.71
dB(A) at 50% load10.61
dB(A) at 100% load24.98

Protection

OCP (over current protection)
OVP (over Voltage protection)
UVP (under Voltage protection)
SCP (short circuit protection)
OTP (over temperature protection)
OPP (over power protection)

Safety certification

CE
CB
TÜV
Nemko (N)-
Semko (S)-
Fimko (FI)-
Demko (D)-
FCC
cRUus-
cTUVus
RCM (Australia)
BSMI
CU (Russia)
CCC

Eco / Efficiency

80 PLUS certificationGold
Efficiency (%) at 230V, 20% load-
Efficiency (%) at 230V, 50% load-
Efficiency (%) at 230V, 100% load-

Environmental directives

Energy Star6.1
ErP
WEEE
RoHs

Cable management / Connectors

Multi-GPU ready
Modular Cable management
Fully modular
Sleeved cables
Flat cables-
Cable length to mainboard (cm)60
Cable length to first connector (cm)55
Maximum cable length (cm)115
All-in-one cable (SATA/PATA/FDD)
No. of cables11
ATX-Motherboard (20+4-pin)1
P8 (CPU)1
P4+4 (CPU)1
P4 (CPU)-
PCI-e 6-pin (GPU)-
PCI-e 6+2-pin (GPU)4
PATA 4-pin4
SATA 15-pin (HDD, Drives)11
FDD (Floppy)1
External fan connectors-

Casing

Dimensions without cable (L x W x D), (mm)170 x 150 x 86
Weight (kg)1.8
ColorBlack

Accessories

Thumb screws-
Screws
Cable ties
Velcro cable ties-
Box/Bag for PSU/Cables-
User manual languagesDE, EN, ES, FR, PL, RU
OCK slot bracket with switch / OCK jumper-
SFX-to-ATX adapter bracket-

Service

Warranty (Years)5
Express replacement service in first yearDE, FR
International hotline / free of charge✓ / DE, FR

Logistics data, RRP

Article numberBN620
EAN code4260052185841
Dimensions, package (L x W x H), (mm)328 x 248 x 102
Gross weight, package (kg)3.38
Pieces per packaging unit6
Dimensions, shipping box (L x W x H), (mm)651 x 282 x 346
Gross weight, shipping box (kg)21.59
RRP (€)169.00
